Swivel feet for machines

Requires use of

Spindle for 40° swivel pad

Metal plate for 40° swivel pad

with fastening holes

3D visualisation

Technical specifications

Add to favourites

Plate in die cast zinc, black powder-coated or stainless steel 1.4305. With or without anti-slip plate in thermoplastic elastomer.

REF	DESIGNATION	D	A	CHARGE
123034	BASE DIECASTZINC D.80 FOR FEET 40	80	55	30000
123035	BASE DIECASTZINC D.100 FOR FEET 40	100	74	35000
123036	BASE DIECASTZINC D.120 FOR FEET 40	120	94	35000
123034i	BASE STAINLESS D.80 FOR FEET 40	80	55	30000
123035i	BASE STAINLESS D.100 FOR FEET 40	100	74	35000
123036i	BASE STAINLESS D.120 FOR FEET 40	120	94	35000

REF	DESIGNATION	D	A	CHARGE
123037	BASE DIECASTZINC D.80 FOR FEET 40	80	55	30000
123038	BASE DIECASTZINC D100 FOR FEET 40	100	74	35000
123039	BASE DIECASTZINC D120 FOR FEET 40	120	94	35000
123037i	BASE STAINLESS D.80 FOR FEET 40	80	55	30000
123038i	BASE STAINLESS D.100 FOR FEET 40	100	74	35000
123039i	BASE STAINLESS D.120 FOR FEET 40	120	94	35000
